UR Robot Reach Training

Demo

The UR robot learning to reach target poses

Overview

This repository contains training code for our specific configured robot, Universal Robot (UR) robotic arm with Robotiq 2F-140 gripper, which is based on the NVIDIA Deep Learning Institute (DLI) course: Train Your Second Robot in Isaac Lab. The project implements a reinforcement learning pipeline where the robot learns to reach randomly sampled target poses within its workspace. The training uses manager-based RL environment architecture from Isaac Lab.

Installation

• Install Isaac Lab by following the installation guide. Please use Isaac Lab with IsaacSim 4.5.0.

• Clone this repository separately from the Isaac Lab installation:

git clone <repository-ssh>
cd Reach

• Using a python interpreter that has Isaac Lab installed, install the library in editable mode:

python -m pip install -e source/Reach

• Verify the installation by listing available tasks:

python scripts/list_envs.py

Usage

Training

Train a PPO agent on the reach task using SKRL:

python scripts/skrl/train.py --task Template-Reach-v0 --headless

Testing

Run a trained policy for evaluation:

python scripts/skrl/play.py --task Template-Reach-Play-v0

Environment Details

Task Specification

• Objective: Reach target end-effector poses (position + orientation)
• Observations: Joint positions, velocities, pose commands, and previous actions
• Actions: Joint position commands (6-DOF for arm)
• Reward Components:
  • Position tracking error (L2 distance to target)
  • Orientation tracking error (quaternion difference)
  • Action rate penalty (smoothness)
  • Joint velocity penalty

Training Configuration

• Algorithm: PPO (Proximal Policy Optimization)
• Network Architecture: 64x64 fully connected layers with ELU activation
• Training Steps: 24,000 timesteps by default
• Environments: 2000 parallel environments (training), 50 (play)

Resources

For a comprehensive walkthrough of this implementation, watch the collaborative tutorial series by LycheeAI and I:
