US.ptiles Schema v6

Demo

Every building in the United States—77 million footprints with business names and details extracted from OpenStreetMap. The source data comes from Protomaps PMTiles, which is derived from OSM's global building dataset.

Binary format for offline GPS → building lookup with full polygon footprints.

Compression Achievement

PTiles v6 compresses the ~130GB US buildings PMTile from protomaps.com into a single ~1.14GB file (99.1% reduction) while preserving full polygon geometry for all 77M+ buildings.

Key techniques enabling this compression:

• Zstd dictionary compression (level 22): Shared dictionary trained on building data
• Delta coordinate encoding: Zigzag + varint for vertex deltas (2-4 bytes/vertex vs 16 bytes raw)
• Delta OSM ID encoding: Sequential IDs within H3 cells compress to 1-2 bytes each
• H3 spatial clustering: Buildings grouped by geographic cell for better compression locality
• Indexed building types: 20 common types as 1-byte indices instead of strings

Overview

Single file containing 77M+ US building footprints with names where available. File size: ~1.14 GB (~15 bytes/building average).

Metric	Value
Total buildings	77,068,235
H3 cells	380,425
File size	~1.14 GB
Bytes per building	~15
Compression	zstd level 22
Dictionary size	512 KB
Coordinate precision	1.1m (10 microdegrees)

File Structure

┌─────────────────────────────────────────────────────────────────┐
│ Header (256 bytes)                                              │
├─────────────────────────────────────────────────────────────────┤
│ Zstd Dictionary (512 KB typical)                                │
├─────────────────────────────────────────────────────────────────┤
│ Spatial Index (H3 cell → block offset/length)                   │
├─────────────────────────────────────────────────────────────────┤
│ Data Blocks (zstd compressed, one per H3 cell)                  │
└─────────────────────────────────────────────────────────────────┘

Header (256 bytes)

Offset	Size	Type	Field	Description
0	8	bytes	magic	PTILESF\x00 (F = footprints)
8	1	uint8	version	6
9	3	-	reserved	Padding for alignment
12	4	float	min_lat	Bounding box south
16	4	float	min_lon	Bounding box west
20	4	float	max_lat	Bounding box north
24	4	float	max_lon	Bounding box east
28	8	uint64	poi_count	Total building count
36	4	uint32	block_count	Number of H3 cell blocks
40	8	uint64	dict_offset	Byte offset to dictionary
48	4	uint32	dict_length	Dictionary size in bytes
52	8	uint64	index_offset	Byte offset to spatial index
60	4	uint32	index_length	Index size in bytes
64	8	uint64	blocks_offset	Byte offset to first data block
72	184	-	reserved	Future use (zeroed)

Byte order: Little-endian throughout.

Spatial Index

H3 resolution 7 cells (~5.16 km² average). Sorted by H3 cell ID for binary search.

┌──────────────────────────────────────────────────────────────┐
│ entry_count (4 bytes, uint32)                                │
├──────────────────────────────────────────────────────────────┤
│ Entry 0                                                      │
│   h3_cell (8 bytes, uint64) - H3 index as integer            │
│   block_offset (6 bytes) - Absolute byte offset to block     │
│   block_length (3 bytes) - Compressed block size             │
│   poi_count (2 bytes, uint16) - Buildings in this cell       │
├──────────────────────────────────────────────────────────────┤
│ Entry 1...N (19 bytes each)                                  │
└──────────────────────────────────────────────────────────────┘

Entry size: 19 bytes (8 + 6 + 3 + 2)

Why 6-byte offset: Supports files up to 281 TB (2^48 bytes). 4 bytes would limit to 4 GB.

Why 3-byte length: Max compressed block size 16 MB (2^24 bytes). Typical blocks are 2-50 KB.

Binary Search Implementation

def find_block_for_cell(index: list[dict], cell: str) -> dict | None:
    cell_int = int(cell, 16)
    left, right = 0, len(index) - 1
    while left <= right:
        mid = (left + right) // 2
        entry_int = int(index[mid]["h3_cell"], 16)
        if entry_int == cell_int:
            return index[mid]
        elif entry_int < cell_int:
            left = mid + 1
        else:
            right = mid - 1
    return None

Data Block

Each block is zstd compressed (level 22) with shared dictionary. Contains all buildings whose centroid falls within the H3 cell.

Decompressed format:

┌──────────────────────────────────────────────────────────────┐
│ Record 0                                                     │
│   record_length (4 bytes, uint32) - Size of record data      │
│   record_data (variable) - Building record                   │
├──────────────────────────────────────────────────────────────┤
│ Record 1...N                                                 │
└──────────────────────────────────────────────────────────────┘

Buildings within a block are sorted by OSM ID for delta encoding efficiency.

Zstd Dictionary Training

The shared dictionary is trained on a representative sample of building data:

• Sample ~10,000 buildings across diverse geographic regions
• Train with zstd --train at 512 KB dictionary size
• Dictionary captures common coordinate delta patterns and string prefixes

Building Record (Binary)

Field	Encoding	Description
osm_id	varint (delta)	Delta from previous OSM ID in block
vertex_count	uint8	Polygon vertex count (max 255)
first_lon	int32	First longitude × 100,000
first_lat	int32	First latitude × 100,000
deltas	varint pairs	Zigzag-encoded delta lon/lat
flags	uint8	Bit flags for optional fields
btype_idx	uint8	Building type (see table)
[btype_str]	uint8 len + UTF-8	Only if btype_idx = 255
[name]	uint16 len + UTF-8	Only if flags & 0x01
[category]	uint8 len + UTF-8	Only if flags & 0x02
[name_src]	uint8 len + UTF-8	Only if flags & 0x04
[poi_osm_id]	uint64	Only if flags & 0x08

Delta Coordinate Encoding

Each subsequent vertex (after the first) is encoded as a pair of zigzag varints.

Coordinate System

Coordinates are stored as microdegrees (degrees × 100,000):

• 1 microdegree ≈ 1.1m at equator
• int32 range: ±21,474° (covers entire Earth with room to spare)
• Precision: ~1.1m at equator, ~0.7m at 50° latitude

Encoding Process

1. Calculate delta from previous vertex (in microdegrees):

   delta_lon = current_lon - previous_lon
   delta_lat = current_lat - previous_lat


   Typical building wall deltas: -5000 to +5000 microdegrees (-55m to +55m)

2. Zigzag encoding converts signed integers to unsigned (small magnitudes → small values):

   zigzag(n) = (n << 1) ^ (n >> 31)

   Examples:
     0 →  0
    -1 →  1
     1 →  2
    -2 →  3
     2 →  4


   This maps small negative numbers to small positive numbers, improving varint efficiency.

3. Varint encoding (protobuf-style, 7 bits per byte, MSB = continuation):

   while value >= 0x80:
       emit(0x80 | (value & 0x7F))
       value >>= 7
   emit(value)

   Byte costs:
     0-127:        1 byte
     128-16383:    2 bytes
     16384-2097151: 3 bytes


Compression Analysis

Delta magnitude	Zigzag value	Varint bytes	Typical usage
0	0	1	Repeated coordinate
±1 to ±63	1-127	1	Very small walls
±64 to ±8191	128-16383	2	Most building walls
±8192+	16384+	3+	Large buildings

Typical building: 5-8 vertices, 2-4 bytes per delta pair = 10-32 bytes for geometry.

Decoding Implementation

def decode_varint(data: bytes, pos: int) -> tuple[int, int]:
    """Decode unsigned varint. Returns (value, bytes_consumed)."""
    result = shift = 0
    start = pos
    while True:
        b = data[pos]
        result |= (b & 0x7F) << shift
        pos += 1
        if not (b & 0x80):
            break
        shift += 7
    return result, pos - start

def zigzag_decode(n: int) -> int:
    """Decode zigzag unsigned to signed integer."""
    return (n >> 1) ^ -(n & 1)

def decode_coordinates(data: bytes, pos: int, first_lon: int, first_lat: int,
                       vertex_count: int) -> tuple[list, int]:
    """Decode all coordinates from delta-encoded data."""
    coords = [[first_lon / 100000, first_lat / 100000]]
    prev_lon, prev_lat = first_lon, first_lat
    start_pos = pos

    for _ in range(vertex_count - 1):
        delta_lon_raw, consumed = decode_varint(data, pos)
        pos += consumed
        delta_lat_raw, consumed = decode_varint(data, pos)
        pos += consumed

        delta_lon = zigzag_decode(delta_lon_raw)
        delta_lat = zigzag_decode(delta_lat_raw)

        prev_lon += delta_lon
        prev_lat += delta_lat
        coords.append([prev_lon / 100000, prev_lat / 100000])

    return coords, pos - start_pos

OSM ID Delta Encoding

Buildings sorted by OSM ID within each block. First building stores full ID as varint, subsequent store delta from previous as varint.

Building 1: OSM ID 130905906 → varint(130905906) = 5 bytes
Building 2: OSM ID 130905912 → varint(6)         = 1 byte
Building 3: OSM ID 130905915 → varint(3)         = 1 byte
Building 4: OSM ID 130905920 → varint(5)         = 1 byte

Typical delta: 1-100 (buildings created in sequence) = 1 byte each.

Flags Byte

Bit	Mask	Field Present	Encoding if present
0	0x01	name	uint16 length + UTF-8
1	0x02	category	uint8 length + UTF-8
2	0x04	name_source	uint8 length + UTF-8
3	0x08	poi_osm_id	uint64 (8 bytes)
4	0x10	height	uint8 (0.5m steps, 0-127.5m)
5-7	-	reserved	-

Building Type Index

20 most common OSM building=* values encoded as 1-byte index:

Index	Type	Index	Type
0	yes	10	shed
1	house	11	detached
2	residential	12	terrace
3	commercial	13	school
4	industrial	14	church
5	retail	15	hospital
6	garage	16	hotel
7	apartments	17	roof
8	office	18	construction
9	warehouse	19	barn
255	(variable)	-	uint8 len + UTF-8 follows

Index 255 indicates a custom string follows (rare building types).

Query Algorithm

1. Convert query lat/lng to H3 cell (resolution 7)
2. Binary search index for matching H3 cell
3. Fetch block at offset (HTTP range request or file seek)
4. Decompress with shared dictionary
5. Iterate building records, accumulating OSM ID deltas
6. Reconstruct polygon from delta coordinates
7. Point-in-polygon test against query point
8. Return first containing building (or nearest within 50m)

HTTP Range Request Pattern

For hosted files, cache header + dictionary + index on client (~1 MB). Each query requires 1 range request for the data block (~2-50 KB compressed).

GET /US.ptiles
Range: bytes=0-786432          # Header + dict + index (once, cached)

GET /US.ptiles
Range: bytes=12345678-12348000 # Single block per query

---

Full Building Decoder (Python)

import struct

BTYPE_REVERSE = {
    0: "yes", 1: "house", 2: "residential", 3: "commercial", 4: "industrial",
    5: "retail", 6: "garage", 7: "apartments", 8: "office", 9: "warehouse",
    10: "shed", 11: "detached", 12: "terrace", 13: "school", 14: "church",
    15: "hospital", 16: "hotel", 17: "roof", 18: "construction", 19: "barn",
}

def decode_building_v6(data: bytes, offset: int, prev_osm_id: int = 0):
    """Decode v6 binary building record. Returns (building_dict, bytes_consumed)."""
    pos = offset

    # OSM ID (delta varint)
    osm_id_delta, consumed = decode_varint(data, pos)
    pos += consumed
    osm_id = prev_osm_id + osm_id_delta

    # Vertex count (1 byte)
    vertex_count = data[pos]
    pos += 1

    # First coordinate (8 bytes: int32 lon, int32 lat)
    first_lon, first_lat = struct.unpack_from("<ii", data, pos)
    pos += 8

    # Delta coordinates (varint zigzag pairs)
    coords, consumed = decode_coordinates(data, pos, first_lon, first_lat, vertex_count)
    pos += consumed

    # Flags (1 byte)
    flags = data[pos]
    pos += 1
    has_name = flags & 0x01
    has_category = flags & 0x02
    has_name_source = flags & 0x04
    has_poi_osm_id = flags & 0x08
    has_height = flags & 0x10

    # Building type (1 byte index or 255 + variable string)
    btype_idx = data[pos]
    pos += 1
    if btype_idx == 255:
        btype_len = data[pos]
        pos += 1
        btype = data[pos:pos + btype_len].decode("utf-8")
        pos += btype_len
    else:
        btype = BTYPE_REVERSE.get(btype_idx, "yes")

    # Calculate centroid
    lats = [c[1] for c in coords]
    lons = [c[0] for c in coords]
    building = {
        "osm_id": osm_id,
        "geometry": {"type": "Polygon", "coordinates": [coords]},
        "centroid_lat": round(sum(lats) / len(lats), 6),
        "centroid_lon": round(sum(lons) / len(lons), 6),
        "building_type": btype,
    }

    # Optional fields
    if has_name:
        name_len = struct.unpack_from("<H", data, pos)[0]
        pos += 2
        building["name"] = data[pos:pos + name_len].decode("utf-8")
        pos += name_len
    if has_category:
        cat_len = data[pos]
        pos += 1
        building["category"] = data[pos:pos + cat_len].decode("utf-8")
        pos += cat_len
    if has_name_source:
        src_len = data[pos]
        pos += 1
        building["name_source"] = data[pos:pos + src_len].decode("utf-8")
        pos += src_len
    if has_poi_osm_id:
        building["poi_osm_id"] = struct.unpack_from("<Q", data, pos)[0]
        pos += 8
    if has_height:
        height_byte = data[pos]
        pos += 1
        building["height_m"] = height_byte * 0.5

    return building, pos - offset

---

Version History

Version	Changes
6	Delta OSM IDs + zigzag varint coords (this)
5	Varint coords, full OSM IDs
4	Binary footprints, fixed-size coords (4 bytes/delta)
3	JSON minimal format (gzip)
1-2	POI points only (no polygons)

---

Reference Implementations

Language	File	Notes
Python	scripts/read_ptiles_footprints.py	Reader (lines 241-254)
Python	scripts/build_ptiles_footprints.py	Writer (encoder)

Dependencies

• h3: Hexagonal spatial indexing (Uber H3 library)
• zstandard: Compression with trained dictionary
• shapely: Point-in-polygon tests (reader only)

---

Size Comparison

Format	Size	Bytes/building
Protomaps PMTile (source)	~130 GB	~1,700
PTiles v4 (fixed coords)	~2.1 GB	~28
PTiles v5 (varint coords)	~1.5 GB	~20
PTiles v6 (delta IDs)	~1.14 GB	~15
